Multi-Ply Conveyor Belt
Explore Vulcotec EP and NN multi-ply conveyor belts. Discuss fabric construction, cover requirements, operating conditions and the specification for your enquiry.
Brand: Vulcotec
Fabric: EP/NN
Fabric strength per ply: 100–630 N/mm
Width: 300–3600 mm
Origin: China
Lead time: Confirmed per order
Product Detail
EP and NN Multi-Ply Conveyor Belts
Vulcotec multi-ply conveyor belts use EP or NN fabric reinforcement. Belt construction and cover grade are selected for the material and conveyor operating conditions.
Product Range
| Item | Specification |
|---|---|
| Fabric types | EP / NN |
| Fabric strength per ply | 100–630 N/mm for both EP and NN |
| Belt width | 300–3600 mm |
| Product origin | China |
Fabric strength per ply is not the total belt strength. Specify the required total belt rating, ply count and construction in your enquiry.
Cover Grades Available to Order
| Grade family | Available grades |
|---|---|
| JIS | JIS-P, JIS-G, JIS-S, JIS-A, JIS-L, JIS-D, JIS-H |
| DIN | DIN-W, DIN-X, DIN-Y, DIN-Z |
| AS | AS-N, AS-M, AS-A |
| RMA | RMA-1, RMA-2 |
These grades are available according to order requirements. Confirm the applicable standard and edition, cover properties, test methods and acceptance criteria in the technical offer. Heat-resistant, cold-resistant and oil-resistant belt types are also available for specification enquiries.
Information to Include in Your Enquiry
- Material, lump size, moisture and loading conditions.
- Total belt strength, number of plies, width, length and top/bottom cover thicknesses.
- Required cover grade, operating temperature and any oil exposure.
- Conveyor speed, inclination, pulley diameters and splice requirements.
- Quantity and delivery destination.
Lead time is confirmed for each order.
For a quotation, email info@vulcotec.com with your application, belt specification, required quantity and destination.
Multi-Ply Conveyor Belt Purchasing Questions
What EP and NN multi-ply belt widths does Vulcotec offer?
Vulcotec offers EP and NN multi-ply conveyor belts in widths from 300 to 3,600 mm. Confirm the required total belt rating, ply count, cover grade and cover thicknesses in your enquiry. The final construction is confirmed for the order.
Does fabric strength per ply mean the total belt strength?
No. Vulcotec's listed EP and NN fabric strength range of 100–630 N/mm is the strength per ply. It is not a statement of the finished belt's total rating. Please specify the required total belt rating, number of plies and construction when requesting a quotation.
Which multi-ply cover grades can be requested?
Available grades include JIS-P/G/S/A/L/D/H, DIN-W/X/Y/Z, AS-N/M/A and RMA-1/2, according to order requirements. Confirm the applicable standard and edition, test methods, cover properties and acceptance criteria in the technical offer. Grade availability is not a claim of third-party certification.
